规格:
距离: 40 km
数据速率: 11.3 Gb/s
协议: 符合 8x光纤通道标准
符合 10x光纤通道标准
10 兼容千兆以太网
兼容无线 CPRI
Low End Case Temperature (°C): -5
High End Case Temperature (°C): 70
Diagnostics: Digital
Transmitter: EML
Receiver: PIN
Voltage Supply: 3.3
Connector: LC
波长: 1550nm
封装:
SFP+
Finisar's FTLX1672D3BCL optical transceivers are Enhanced Small Form Factor Pluggable (SFP+) transceivers designed for use in 10-Gigabit multi-rate links up to 40km of G.652 single mode fiber. They are compliant with SFF-8431, SFF-8432 and 10GBASE-ER, and support 10G Fibre Channel, as well as CPRI option 2 through 8, over 40km links.
Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472. The optical transceiver is compliant per RoHS Directive 2011/65/EU. See Finisar Application Note AN-2038 for more details.
