规格:距离: 100 m数据速率: 8.5 Gb/s协议: 兼容 1x 光纤通道 符合 2x光纤通道标准 符合 4x光纤通道标准 符合 8x光纤通道标准Low End Case Temperature (°C): -5Hig...
规格:
距离: 100 m
数据速率: 8.5 Gb/s
协议: 兼容 1x 光纤通道
符合 2x光纤通道标准
符合 4x光纤通道标准
符合 8x光纤通道标准
Low End Case Temperature (°C): -5
High End Case Temperature (°C): 85
Diagnostics: Digital
Transmitter: VCSEL
Receiver: PIN
Voltage Supply: 3.3
Connector: LC
波长: 850 nm 波段
封装:
SFP+
Finisar's FTLF8528P3BxV SFP+ transceivers are designed for use in Fibre Channel links up to 8.5 Gb/s data rate over multimode fiber.They are compliant with FC-PI-4 Rev. 8.00 and SFF-8472 Rev 11.0, and compatible with SFF-8432 and applicable portions of SFF-8431 Rev. 4.1. The product is RoHS compliant and lead-free per Directive 2002/95/EU and Finisar Application Note AN-2038.
