规格:距离: 550 m数据速率: 4.25 Gb/s协议: 兼容千兆光纤以太网 符合 1x光纤通道标准 符合 2x光纤通道标准 符合 4x光纤通道标准Low End Case Temperatur...
规格:
距离: 550 m
数据速率: 4.25 Gb/s
协议: 兼容千兆光纤以太网
符合 1x光纤通道标准
符合 2x光纤通道标准
符合 4x光纤通道标准
Low End Case Temperature (°C): -20
High End Case Temperature (°C): 85
Diagnostics: Digital
Transmitter: VCSEL
Receiver: PIN
Voltage Supply: 3.3
Connector: LC
波长: 850 nm 波段
封装:
SFP
Finisar's FTLF8524P2xNL Small Form Factor (SFP) transceivers are compatible with the SFP Multi-Sourcing Agreement (MSA). They are compatible with Fibre Channel FC-PI-2 Rev. 7.0. Rate selectable versions are also compatible with Gigabit Ethernet as specified in IEEE Std 802.3. The optical transceiver is compliant per the RoHS Directive 2011/65/EU.See Finisar Application Note AN-2038 for more details. Digital diagnostics functions are available via the 2-wire serial bus specified in the SFP MSA.
